Ayrton Digital Lighting

Ayrton Diablo-S

Ayrton Diablo-S
Ayrton Digital Lighting

Ayrton Diablo-S

In Stock and ready to ship rentals

People who were interested in this product also liked:

Details

Shipping

Details

The Ayrton Diablo-S is a highly advanced, versatile profile luminaire that is designed to offer maximum efficiency and functionality in a compact form factor. Based on the ultra-compact Mistral format, this luminaire is the smallest and lightest in its category, weighing only 21.8 kg. It features an impressive output of 19,000 lumens and a native CRI greater than 70, making it a powerful lighting tool for even the most demanding lighting designers.

The Diablo-S is equipped with a 13-element 7.5:1 zoom high-resolution optic system with a beam aperture of 7° to 53°, allowing for accurate positioning and framing of objects at any angle. It also features an ultra-compact high-output 550 W power supply that feeds eight additional motors in the framing system, fitting into the original Mistral format. This allows for the miniaturization of the framing system while maximizing the performance level.

Other notable features of the Diablo-S include a fast iris diaphragm with adjustable dynamic effects, a light frost filter, and a graphic animation effect-wheel with continuous rotation in both directions. It also includes an electronic dimmer, allowing for perfect light adjustment from 0 to 100% without color variation, and a white or color strobe effect with speed adjustment from 1 to 25 flashes per second.

The Ayrton Diablo-S is a highly advanced, versatile profile luminaire that is designed to offer maximum efficiency and functionality in a compact form factor. Based on the ultra-compact Mistral format, this luminaire is the smallest and lightest in its category, weighing only 21.8 kg. It features an impressive output of 19,000 lumens and a native CRI greater than 70, making it a powerful lighting tool for even the most demanding lighting designers.

The Diablo-S is equipped with a 13-element 7.5:1 zoom high-resolution optic system with a beam aperture of 7° to 53°, allowing for accurate positioning and framing of objects at any angle. It also features an ultra-compact high-output 550 W power supply that feeds eight additional motors in the framing system, fitting into the original Mistral format. This allows for the miniaturization of the framing system while maximizing the performance level.

Other notable features of the Diablo-S include a fast iris diaphragm with adjustable dynamic effects, a light frost filter, and a graphic animation effect-wheel with continuous rotation in both directions. It also includes an electronic dimmer, allowing for perfect light adjustment from 0 to 100% without color variation, and a white or color strobe effect with speed adjustment from 1 to 25 flashes per second.

Shipping

This equipment has been inspected by a Main Light certified technician at one of our locations.

01

Features

  • 3 Series - Source300 W - 7000 KDiablo-S
  • Lumens19,000Diablo-S
  • Native CRIgreater than 90Diablo-TC
  • Beam Aperture7° to 53°
  • Front Lens119 mm
02

Specifications

Optics

  • 13-element 7.5:1 zoom high-resolution optic system
  • Beam aperture: 7° to 53°
  • Fast motorised linear zoom
  • Tempered anti-reflective coated lenses
  • 119 mm frontal lens for greater performance

Light Source

Diablo-S

  • 26,500 lumens, 8000 K white-light engine
  • Total luminaire output: up to 19,000 lumens
  • Colour temperature output: 7000 K
  • CRI: greater than 70

Diablo-TC

  • 20,500 lumens 7000 K white-light engine
  • Total luminaire output: up to 14,000 lumens
  • Colour temperature output: 6000 K
  • CRI: greater than 90

Diablo-S & Diablo-TC

  • Rated life (L70): up to 40,000 hours
  • Flicker-free source management suitable for TV applications and all video-recorded events

Movement

  • Extremely accurate positioning
  • Moving-head operated with either 8- or 16-bit resolution
  • High-resolution stepper motors operated via microprocessors to ensure extreme accuracy and smooth movement
  • Pan and tilt with automatic repositioning
  • Moving-head range: 540° (pan), 270° (tilt)

Colours

  • Sophisticated colour mix system providing CMY colour mixing
  • Variable CTO colour temperature correction
  • Fixed colour wheel with seven complementary colours

Gobos

  • Indexable rotating gobo wheel with 7 high-precision glass gobos, plus open position
  • Adjustable-speed rotating gobo in both directions
  • Gobo diameter: 25.5 mm
  • Image diameter: 20.0 mm
  • Gobo thickness: 1.1 mm – 2.2 mm

Framing System

  • 4 individually positionable shutter blades
  • Rotation of the framing system module: +/- 45°

Iris Diaphragm

  • Fast iris diaphragm with adjustable dynamic effects
  • Iris range: 15% to 100% open

Frost

  • Light frost filter (Heavy frost filter in option)

Effects

  • Graphic animation effect-wheel with continuous rotation in both directions
  • 5-facet circular indexable rotating prism

Dimmer / Strobe

  • Electronic dimmer, allowing perfect light adjustment from 0 to 100% without colour variation
  • White or colour strobe effect, with speed adjustment from 1 to 25 flashes per second

Software Features

  • Local DMX addressing of luminaire and optional parameters through a built-in LCD control panel
  • Remote DMX addressing of luminaire and optional parameters through a standard RDM DMX controller
  • Information menu including hour counter, temperature, software version

Hardware Features

  • Graphic LCD display for addressing and special functions settings, with flip function
  • Clicking jog wheel to set functions
  • Excess-temperature protection
  • Integrated wireless CRMX TiMo™ RDM receiver from LumenRadio™
  • XLR 5-pin male and female connectors for DMX connection
  • powerCON TRUE1 male and female connectors for power connection

Control

  • DMX 512 protocol, through DMX cable or a wireless system
  • DMX-RDM compatible
  • Stand-alone mode and Master/Slave modes
  • Local control panel, with LCD display
  • Choice of 3 DMX modes (from 34 to 56 DMX channels)

Power Supply

  • Electronic supply with active PFC
  • 100 to 240 Volts – 50/60 Hz
  • Power: 550 W maximum

Cooling System

  • Advanced liquid cooling system
  • Self-adjusting variable speed fans for quiet operation (Auto mode)
  • Selectable ventilation user modes including a new Silent Mode
  • Safety protection against temperatures excesses

Housing

  • Moving-head skeleton made of aluminium and steel metal plates
  • Base in die-cast aluminium
  • Aluminium and copper heatsinks
  • Moulded covers in self-extinguishing fire retardant ABS PC (V0 class)
  • Two-side handles for transportation
  • Four heavy-duty feet for better stability
  • IP20 protection rating
  • Exterior finish: black (Carbon)

Installation

  • Fastening-bracket system: two Omega ¼ turn brackets designed for use with standard clamps
  • Mounting points: four ¼ turn locking fittings allowing installation of Omega brackets on luminaire
  • Safety-cable attachment point

Operating Parameters

  • Operating positions: all (device on floor or fixed to a support)
  • Maximum permitted ambient temperature (Ta max): 45 °C (113 °F)
  • Minimum permitted ambient temperature (Ta min): -10 °C (14 °F)
  • Minimum usage distance: 1.5 m (4.92 ft)

Compliance

EU (EMC & LVD):

  • EMC Directive 2014/30/EU
  • LVD Directive 2014/35/EU

US (Safety & EMC):

  • UL 1573
  • FCC Part 15, Subpart B: 2018

Size

  • Product: 365 x 591 x 212 mm (l x h x d)
  • Flight-case foam: 430 x 660 x 280 mm (l x h x d)

Weight

  • Product: 21.8 kg
