onAir Panel 1 IP LED Soft Light
Only available out of Main Light Tri-State in Teterboro, New Jersey.
Ready to ship
Details
The Chauvet onAir Panel 1 IP is a durable, IP65-rated LED soft light designed for broadcast, film, and special events, both indoors and outdoors. This 1x1 format panel offers exceptional white light quality with high CRI and TLCI scores, making it perfect for on-location shoots in any weather condition. It features advanced color temperature control, smooth dimming, and customizable effects to achieve precise lighting for any project. With multiple mounting options, wireless control capabilities, and the ability to run on external battery packs, the onAir Panel 1 IP provides flexibility and ease of use for all your lighting needs.
Shipping
Features
- Full-spectrum LED soft light in 1x1 format for broadcast, film, and special events
- IP65 rating for reliable outdoor use in all weather conditions
- Linear color temperature presets from 2800K to 8000K with high CRI and CQS
- Virtual color wheel with gel color-matched options
- +/- green adjustment and emulated red-shift for precise color control
- Wireless control with RDM and CRMX compatibility
- Adjustable PWM settings to avoid flicker during filming
- Ultra-smooth 16-bit dimming for a professional finish
- Easy-to-switch mounting options (Jr Pin or Omega Bracket)
- Rugged build with drop-in slot for diffusers or intensifiers (sold separately)
- Onboard control for full access to features without needing a separate controller
- Optional external battery power via 28 VDC input for remote flexibility
Specifications
- Light Source: 224 RGB LEDs (1.4 W), 224 WW LEDs (0.50 W), 50,000-hour lifespan
- Color Temperature Range: 2800K – 8000K
- CRI: 95
- Beam Angle: 99.3°
- Field Angle: 154°
- Lumens: 10,092
- Illuminance: 165 lux @ 5m
- Strobe Rate: 0–28 Hz
- Control Protocols: Art-Net, sACN, DMX, CRMX, RDM
- DMX Channels: 1, 3, 4, 5, 6, 8, 10, 11, 15, 16
- Input Voltage: 100–240 VAC, 50/60 Hz (auto-ranging)
- Power Consumption: 184 W @ 120 V, 187 W @ 208 V, 180 W @ 230 V
- Dimensions: 22 x 5.74 x 21.81 in (559 x 146 x 554 mm)
- Weight: 28 lb (12.7 kg)
- IP Rating: IP65
- Operating Temperature: -4°F to 113°F (-20°C to 45°C)
- Certifications: CE, MET, FCC
