Fuze Max Profile
$4,795
Depot Warranty:
60-Day Depot Warranty
Condition:
Excellent
Ships from:
United States
Used Sales This equipment has been inspected by a Main Light certified technician at one of our locations.
Details
The Elation Fuze Max Profile is a high-quality, full spectrum automated LED framing fixture designed for precision lighting applications such as theater and television. It features an 800W 5-color homogenized LED array consisting of Red, Green, Blue, Mint, and Amber sources with a CRI of 92, providing accurate color reproduction and dynamic whites. The fixture includes a rotating gobo wheel, fixed gobo wheel, animation wheel, dual frost, prism, iris, and a full blackout framing system, making it a comprehensive feature set for any automated framing fixture. The zoom range varies from 7° to 53°, and the fixture has a large 140mm front aperture. It also has 4 DMX channel modes, a 4-button touch control panel, and supports DMX, RDM, Art-NET, and sACN protocols. It has a weight of 76.3 lbs. and is CE, cETLus, and IP20 approved.
Downloads
Features
- Full Spectrum 800W RGBMA LED Engine
- Precise dynamic whites from 2400 - 8500K
- Instant color changes, Natural color transitions
- Rich and intense primary colors
- Rotating and Fixed Gobos plus Animation Wheel
- Full Blackout Framing System
- Iris, Prism, and Dual Frost
- Wide Zoom Range from 7° to 53°
- Large 140mm front aperture
Specifications
PHOTOMETRIC DATA
- 21.000 Total Lumen Output
- CRI 92
- Zoom Range 7° - 53°
- Beam Angle 6.6° - 50.3°
- Field Angle 7.8° - 55°
EFFECTS
- Motorized Zoom
- 4 Rotating Full Blackout Framing Blades, +/- 60° Index
- Dual Variable Frost Filter (Medium/ Wash)
- 4 Facet Round, 4 Facet Linear Prism
- Motorized Iris
- Variable 16-bit Dimming Curve Modes
- High Speed Electronic Shutter and Strobe
COLOR
- RGBMA Color Array
- CMY Emulation
- Virtual Color Correction
- Green/Magenta Shift
- Virtual Gel Swatch Book
GOBOS
- 1x 6 Rotating / Indexing Interchangeable Glass Gobos
- 1x 7 Fixed Interchangeable Glass Gobos
- Animation Wheel
CONTROL / CONNECTIONS
- 4 DMX Channel Modes (RGBMA 40/61) (CMY 38/57)
- 16-bit Pan, Tilt, and Dimming Control
- DMX Adjustable LED Frequency
- DMX, RDM, Art-NET, sACN Protocol Support
- 4 Button Touch Control Panel
- Full Color 180° Reversible LCD Menu Display
- 16 Bit Resolution Adjustable Movement
- 5pin DMX In/Out
- Locking Ethernet In/Out
- IP65 Locking Power In
- With Wired Digital Communication Network
SIZE / WEIGHT
- Length: 18.19” (462mm)
- Width: 21.26" (540mm)
- Width with Snoot: 23.2" (590mm)
- Vertical Height: 28.3" (719mm)
- Vertical Height with Snoot: 30.4" (771mm)
- Weight: 76.3 lbs. (34.6kg)
ELECTRICAL / THERMAL
- AC 100-240V - 50/60Hz
- 1126W Max Power Consumption
- 14°F to 113°F (-10°C to 45°C)
APPROVALS / RATINGS
- CE | cETLus | IP20
