MA Lighting
grandMA3 Full Size
120 physical playbacks, assignable x-keys, and 12,288 control parameters.
Ready to ship
Details
The grandMA3 full-size console is the flagship model of the grandMA3 range, designed for professionals in the entertainment industry. It offers a flexible playback platform with 120 physical playbacks, assignable x-keys, and 12,288 control parameters. The console features a huge multi-touch screen, assignable level wheel sections, and dual encoders for intuitive control. It is compatible with grandMA2 and grandMA3 software, and supports the new GDTF format for fixture control. The console has six DMX outputs, a built-in UPS, and various connectors.
Downloads
Shipping
Features
- Real-time control for up to 250 000 parameters per session in connection with grandMA3 processing units
- 6 DMX outputs, 1 DMX input
- 3 internal foldable monitor multi-touch screens
- 3 internal letterbox multi-touch screens
- 2 internal multi-touch command screens
- 2 external multi-touch screens can be connected
- 2 multipurpose level wheels
- 2 multipurpose single encoder
- 71 rotary RGB backlit encoder
- 5 backlit dual encoders
- 30 backlit motorized 60 mm faders
- 120 separate playbacks
- 16 assignable x-keys
- Integrated keyboard drawer
- Built-in uninterruptible power supply (UPS)
- 3 etherCON connectors, 6 USB connectors
- 2 backlit motorized A/B faders 100 mm
- Individually backlit and dimmable silent (clickless) keys
Specifications
- Parameters: 12,288 (HTP/LTP)
- Parameters Mode2: 8,192 (HTP/LTP)
- Operating voltage/Supply voltage: AC 100 - 240 V; 50/60 Hz
- Power: max. 300 VA
- Operating Temperature: 0 °C up to 40 °C / 32 °F up to 104 °F
- Dimensions:
- 1,256 x 539 x 181 mm / 50 x 22 x 8 in (width x depth x height, folded and drawer closed)
- 1,256 x 584 x 409 (max. 450) mm / 50 x 23 x 17 (max. 18) in (width x depth x height, unfolded for operation)
- 1,256 x 871 x 255 mm / 50 x 35 x 10 in (width x depth x height, maximally unfolded and drawer opened)
- Net weight: 44 kg / 98 lbs
- Connectors:
- 1 x powerCON TRUE1
- 3 x etherCON/RJ45
- 6 x DMX512-A Out (5pin XLR female)
- 1 x DMX512-A In (5pin XLR male)
- 1 x MIDI In (5pin DIN female)
- 1 x MIDI Out (5pin DIN female)
- 1 x Linear Timecode (3pin XLR female)
- 1 x Audio In (3pin XLR female)
- 1 x GPI General Purpose Interface (D-SUB DE9 female) for remote control
- 2 x DisplayPort 1.2 for external screens
- 2 x S/PDIF In and Out
- 3 x USB 2.0 (type A)
- 3 x USB 3.0 (type A)
- 2 x LED desk light (4pin XLR female)
