MegaPointe

LIGHT SOURCE

Osram Sirius HRI 470 W RO

LIGHT OUTPUT

MEGA bright 2.215.000 lx @ 5 m

ZOOM RANGE

1.8°– 21° beam mode, 3°– 42° spot mode

EFFECTS

rotating and static gobo wheel, animation wheel, 12 beam and flower effects

SOURCE

• Lamp: Discharge short arc lamp with integrated reflector
• Approved model: Osram Sirius HRI 470 W RO
• Lifetime: 1.500 hours @ 470W Standard mode, 2.000 hours @ 380W Eco mode
• CRI: 80/90
• CCT Light Output: 6.300 K, CCT Lamp: 7.500 K
• Control: Automatic and remote on/off
• Ballast: Electronic

OPTICAL SYSTEM

• Robe’s proprietary optical design (Patent pending).
• Zoom optical system: 14:1
• Zoom range:
  • 1.8°– 21° beam mode
  • 3°– 42° spot mode
• Output lens diameter: 150 mm
• Fixture total lumen output: 20.375 lm
• Light output:
  • Beam mode 1.8°: 2.215.000 lx @ 5 m
  • Beam mode 1.8°: 137.500 lx @ 20 m
  • Spot mode 3°: 715.300 lx @ 5 m
  • Spot mode 3°: 44.710 lx @ 20 m

DYNAMIC EFFECTS

• Cyan: 0 – 100%
• Magenta: 0 – 100%
• Yellow: 0 – 100%
• Colour Wheel: 13 dichroic filters + white
• Rotating gobo wheel: 9 rotating, indexable and replaceable gobos + open
• Static gobo wheel: 14 gobos + open
• Animation wheel: Aluminium animation wheel, used alone or in combination with gobos, rotating in both directions at variable speed
• Innovative Effect Engine consisting of 6 prisms placed on two wheels, producing 12 various Beam and Flower effects (Patent pending)
• Beam shaper emulating framing shutters and creating rectangular beam shapes, rotatable and indexable (Patent pending)
• Frost: variable 1° (light) and 5° (medium)
• Motorized zoom and focus
• Remote Hot-spot control: adjustable from 5:1 to 2.5:1 in spot mode and from 7:1 to 2.7:1 in beam mode (Patent pending)
• Pre-programmed random strobe & pulse effects
• Dimmer: 0 – 100%

CONTROL AND PROGRAMMING

• Setting & Addressing: ROBE Navigation System 2 (RNS2)
• Display: QVGA Robe touch screen with battery backup, gravitation sensor for auto screen positioning, operation memory service log with RTC, stand-alone operation with 3 editable programs (each up to 100 steps), built-in analyser for easy fault finding
• Protocols: USITT DMX-512, RDM, ArtNet, MA Net, MA Net2, sACN
• Wireless CRMX™ technology from Lumen Radio (on request)
• DMX Protocol modes: 2
• Control channels: 39,34
• Pan/Tilt resolution: 8 or 16 bit
• Colour wheel positioning: 8 or 16 bit
• CMY: 8 bit
• CRI Selection: 80 or 90
• Rotating gobo wheel positioning: 8 bit
• Gobo indexing & rotation: 8 or 16 bit
• Static gobo wheel positioning: 8 bit
• Animation wheel: 8 bit
• Animation wheel rotation: 8 or 16 bit
• Prism indexing & rotation: 8 bit
• Frost: 8 bit
• Zoom: 8 or 16 bit
• Focus: 8 or 16 bit
• Hot-Spot: 8 bit
• Dimmer: 8 or 16 bit

MOVEMENT

• Pan movement: 540°
• Tilt movement: 270°
• Movement control: Standard and Speed
• Automatic Pan/Tilt position correction
• EMS™: Electronic Motion Stabilizer system for Pan & Tilt reducing beam deviation caused by truss movement or vibration (Patent pending)

ROTATING GOBOS

• Glass gobos: 9 rotating gobos
• Outside diameter: 15.9 mm
• Image diameter: 12.5 mm
• Thickness: 1.1 mm
• High temperature borofloat or better glass
• "SLOT&LOCK" system for easy replacement of gobos

STATIC GOBOS

• Aluminium wheel with fixed gobos: 10 gobos & 4 beam reducers + open position

THERMAL SPECIFICATION

• Maximum ambient temperature: 45 °C (113 °F)
• Maximum housing temperature: 80 °C (176 °F)
• Minimum operating temperature: -5 °C (23 °F)

ELECTRICAL SPECIFICATION AND CONNECTIONS

• Power supply: Electronic auto-ranging
• Input voltage range: 100-240 V, 50/60 Hz
• Power consumption: 670 W at 230 V / 50 Hz
• Power in connector: Neutrik powerCON TRUE1
• DMX and RDM data in/out: Locking 3-pin & 5-pin XLR
• Ethernet port in: RJ45

APPROVALS

• CE Compliant
• cETLus Compliant

MECHANICAL SPECIFICATION

• Height: 640 mm (25.2”) - head in vertical position
• Width: 396 mm (15.6”)
• Depth: 230 mm (9.1”)
• Weight: 22 kg (48.5 lbs)

RIGGING

• Mounting positions: Horizontally or vertically
• Universal operating position
• Mounting points: 2 pairs of 1/4-turn locking points
• 2x Omega adaptors with 1/4-turn quick locks
• Pan and Tilt transport locks
• Safety cable attachment point
