Astera

Titan Tube 1M

Ready to ship

People who were interested in this product also liked:

Pixel Brick Rental
Astera Pixel Brick
See more
ECL Fresnel Rental Image
EclFresnel CT+M
See more

Details

The Astera Titan Tube 1M is a film lighting tube designed for the broadcasting, cinema, and film industries, offering optimized performance with an ultra-high TLCI, a very high CRI, and peak brightness for superior image quality. Equipped with an LG Chem Lithium-ion battery, the tube has a runtime of up to 20 hours and a lifetime of 70% after 300 cycles, and accepts wired DMX via a special power/data combination cable, as well as various wireless modules, with a range of 300m or 330 yards. The backside display allows for HSI control, and the tube includes wired and wireless DMX (CRMX & W-DMX), with 16 pixels for greater control. The Astera Titan Tube 1M has a sturdy construction with a polycarbonate housing and metal endcap, is rated IP65, and can withstand 0-100% relative humidity and an operating temperature range of 0-40 C or 32-104 F, making it a versatile and reliable lighting tool for film and broadcasting professionals.

Downloads

Shipping

Features

Optical

  • Colors: Red, Green, Blue, Mint, Amber
  • Total LED power: 72W
  • Maximum power draw: 48W
  • TLCI: ≥96
  • CRI: ≥96
  • Luminous flux: 2900Lm
  • Emittance @1m: 785Lx
  • Strobe:  0-25Hz
  • Beam Angle: 120Ëš
  • Field Angle: 180Ëš
  • Pixels: 16

Electrical

  • Battery: LG Chem Lithium-ion
  • Battery Lifetime: 70% after 300 cycles
  • Battery Runtime: Up to 20 hours
  • LED Lifetime: 50.000 Hours
  • Charging time (nominal): 3 Hours
  • Input Voltage : 24V 2A

Control

  • Backside Display with HSI control
  • Infrared
  • Wireless Modules: 865-870MHz | 902-928MHz | 2.4GHz
  • Range: 300m | 330 Yards
  • DMX: Wired + Wireless (CRMX & W-DMX)

Specifications

  • Housing: Polycarbonate, metal endcap
  • IP Rating: IP65
  • Relative humidity: 0-100%
  • Operating Temperature: 0-40 ËšC | 32-104 ËšF
  • Weight: 1.35kg |3Lbs
  • Dimensions: Ø42 x 1035mm | Ø1.6” x H40.7”
