Elation

Fuze Max Spot

Elation Fuze Max Spot
Elation

Fuze Max Spot

In Stock and ready to ship rentals

Powerful and Versatile Used FUZE MAX SPOT™ Stage Lighting Fixture.

People who were interested in this product also liked:

Details

Shipping

Details

The FUZE MAX SPOT™ is a highly versatile, automated LED Spot fixture specifically designed for theatre, television and various other precision lighting applications. The device features a full spectrum 92 CRI engine that utilizes an 800W 5-color homogenized LED array, consisting of Red, Green, Blue, Mint and Amber sources, which guarantees accurate color reproduction and dynamic whites. Additionally, it delivers an output of over 21,000 lumens, and features virtual color temperature, Magenta/Green adjustment and CMY emulation, providing designers with quick access to an impressive LED color range. The FUZE SPOT MAX comes equipped with a range of advanced features, including two rotating gobo wheels, a fixed gobo wheel, an animation wheel, dual frost, prism, iris and a wide zoom range of 7° to 53°, and a large 140mm front aperture, making it an extremely powerful and quiet automated spot fixture for any application where outstanding and compelling color range and quality is required.

The FUZE MAX SPOT™ is a highly versatile, automated LED Spot fixture specifically designed for theatre, television and various other precision lighting applications. The device features a full spectrum 92 CRI engine that utilizes an 800W 5-color homogenized LED array, consisting of Red, Green, Blue, Mint and Amber sources, which guarantees accurate color reproduction and dynamic whites. Additionally, it delivers an output of over 21,000 lumens, and features virtual color temperature, Magenta/Green adjustment and CMY emulation, providing designers with quick access to an impressive LED color range. The FUZE SPOT MAX comes equipped with a range of advanced features, including two rotating gobo wheels, a fixed gobo wheel, an animation wheel, dual frost, prism, iris and a wide zoom range of 7° to 53°, and a large 140mm front aperture, making it an extremely powerful and quiet automated spot fixture for any application where outstanding and compelling color range and quality is required.

Shipping

This equipment has been inspected by a Main Light certified technician at one of our locations.

01

Features

  • Full Spectrum 800W RGBMA LED Engine
  • Precise dynamic whites from 2400 - 8500K
  • Instant color changes, Natural color transitions
  • Rich and intense primary colors
  • Dual Rotating and Fixed Gobos plus Animation Wheel
  • Iris, Prism, and Dual Frost
  • Wide Zoom Range from 7° to 53°
  • Large 140mm front aperture
02

Specifications

SOURCE

  • 800W 6,500K RGBMA LED Engine
  • 30,000 Hour Average LED Life*

PHOTOMETRIC DATA

  • 21.000 Total Lumen Output
  • CRI 92
  • Zoom Range 7° - 53°
  • Beam Angle 6.6° - 50.3°
  • Field Angle 7.8° - 55°

EFFECTS

  • Motorized Zoom
  • Dual Variable Frost Filter (Medium/ Wash)
  • 4 Facet Round, 4 Facet Linear Prism
  • Motorized Iris
  • Variable 16-bit Dimming Curve Modes
  • High Speed Electronic Shutter and Strobe
  • Pan Angle: 540° / 630°
  • Tilt Angle: 250°

COLOR

  • RGBMA Color Array
  • CMY Emulation
  • Variable CCT 2400K - 8500K
  • Green/Magenta Shift
  • Virtual Gel Swatch Book

GOBOS

  • 2x 6 Rotating / Indexing Interchangeable Glass Gobos
  • 1x 7 Fixed Interchangeable Glass Gobos
  • Animation Wheel

CONTROL / CONNECTIONS

  • 4 DMX Channel Modes (RGBMA 34/44) (CMY 32/40)
  • 16-bit Pan, Tilt, and Dimming Control
  • DMX Adjustable LED Frequency
  • DMX, RDM, Art-NET, sACN Protocol Support
  • 4 Button Touch Control Panel
  • Full Color 180° Reversible LCD Menu Display
  • 16 Bit Resolution Adjustable Movement
  • 5pin DMX In/Out
  • Locking Ethernet In/Out
  • IP65 Locking Power Cable In
  • With Wired Digital Communication Network

SIZE / WEIGHT

  • Length: 18.19” (462mm)
  • Width: 21.26" (540mm)
  • Width with Snoot: 23.2"" (590mm)
  • Vertical Height: 28.3" (719mm)
  • Vertical Height with Snoot: 30.4" (771mm)
  • Weight: 76.2 lbs. (34.5kg)

ELECTRICAL / THERMAL

  • AC 100-240V - 50/60Hz
  • 1214W Max Power Consumption
  • 14°F to 113°F (-10°C to 45°C)
  • BTU/hr (+/- 10%) 3839.66
