Elation

Cuepix 16 IP RGBW 4x4

Elation Cuepix 16 IP RGBW 4x4
Elation

Cuepix 16 IP RGBW 4x4

In Stock and ready to ship rentals

People who were interested in this product also liked:

Details

Shipping

Details

The CUEPIX 16IP is a dynamic, outdoor-rated luminaire panel ideal for creating stunning lighting effects. With its 4x4 array of 16 powerful 30W RGBA COB LEDs, it offers brilliant color mixing and superior light intensity. Offering a 62° beam and 87° field angles, 16-bit dimming, and high-speed electronic shutter and strobe, it allows for complete lighting control.

The CUEPIX 16IP supports full pixel control with pixel flip modes and features an RGB+ dynamic amber channel mode, ensuring detailed color effects. With adjustable LED refresh rate and gamma brightness, it offers flicker-free operation, perfect for broadcast TV and film.

Equipped with DMX, RDM, Kling-NET, and Art-NET protocol support, it ensures seamless integration with your current systems. This noiseless, fan-free luminaire is suitable for noise-sensitive applications and has a universal auto-switching power supply (100-240v) for convenience.

Its robust IP65 rating and locking connections for DMX, Ethernet, and power cables make it reliable for outdoor use. A 90° adjustable and fixed yoke bracket, along with integrated alignment pins and interlocks, provide versatile rigging options. The full-color 180° reversible LCD control panel simplifies use, and optional omega brackets are available.

Despite its powerful capabilities, the CUEPIX 16IP maintains a compact size, measuring 17.3" in length and width and weighing 33.0 lbs. It's designed to work efficiently in a wide temperature range of 14°F to 113°F, making it an excellent choice for various environments and applications.

The CUEPIX 16IP is a dynamic, outdoor-rated luminaire panel ideal for creating stunning lighting effects. With its 4x4 array of 16 powerful 30W RGBA COB LEDs, it offers brilliant color mixing and superior light intensity. Offering a 62° beam and 87° field angles, 16-bit dimming, and high-speed electronic shutter and strobe, it allows for complete lighting control.

The CUEPIX 16IP supports full pixel control with pixel flip modes and features an RGB+ dynamic amber channel mode, ensuring detailed color effects. With adjustable LED refresh rate and gamma brightness, it offers flicker-free operation, perfect for broadcast TV and film.

Equipped with DMX, RDM, Kling-NET, and Art-NET protocol support, it ensures seamless integration with your current systems. This noiseless, fan-free luminaire is suitable for noise-sensitive applications and has a universal auto-switching power supply (100-240v) for convenience.

Its robust IP65 rating and locking connections for DMX, Ethernet, and power cables make it reliable for outdoor use. A 90° adjustable and fixed yoke bracket, along with integrated alignment pins and interlocks, provide versatile rigging options. The full-color 180° reversible LCD control panel simplifies use, and optional omega brackets are available.

Despite its powerful capabilities, the CUEPIX 16IP maintains a compact size, measuring 17.3" in length and width and weighing 33.0 lbs. It's designed to work efficiently in a wide temperature range of 14°F to 113°F, making it an excellent choice for various environments and applications.

Shipping

This equipment has been inspected by a Main Light certified technician at one of our locations.

01

Features

  • IP65 outdoor-rated for robust performance in various weather conditions
  • 4x4 array of 16 30W 4-in-1 RGBA COB LEDs for bright and dynamic lighting effects
  • 62° beam and 87° field angles for comprehensive coverage
  • Full pixel control with 5 pixel flip modes for enhanced visual dynamics
  • RGB+ Dynamic Amber modes for a broader color spectrum
  • 16-bit dimming and variable dimming curve modes for precise brightness control
  • High-speed electronic shutter and strobe for rapid light adjustments
  • Flicker-free operation suitable for TV and film applications
  • Noiseless operation due to fan-free design
  • DMX, RDM, Kling-NET, and Art-NET protocol support for seamless integration
  • Versatile rigging options with 90° adjustable and fixed yoke brackets, integrated alignment pins, and interlocks
  • Full color 180° reversible LCD control panel for easy navigation and control
  • Adjustable LED refresh rate and gamma brightness for optimal visual performance
02

Specifications

  • 16 30W 4-IN-1 RGBA COB LEDs with 50,000-hour average lifespan
  • 6,400+ total lumen output
  • Beam/Field angles: 62°/87°
  • Lux at 1m (full on): 6,809 LUX 633 FC
  • Control options: DMX, RDM, Kling-Net, and Art-NET protocols
  • Connectors: IP65 Locking 5pin XLR DMX, RJ45 Ethernet, Power In/Out
  • DMX channel modes: 14 (128 total channels)
  • Adjustable refresh rate: 900-25,000 Hz
  • Adjustable gamma brightness: 2.0, 2.2, 2.4, 2.8
  • Dimensions: 17.3" (L) x 8.1" (W) x 17.3" (H)
  • Weight: 33.0 lbs. (15.0 kg)
  • Operating temperature range: 14°F to 113°F (-10°C to 45°C)
  • Power requirements: AC 100-240V - 50/60Hz, 520W max power consumption
