The Rogue Outcast 1 BeamWash is a versatile, IP65 rated, lightweight LED lighting fixture. It boasts seven 45W RGBW LEDs and a 12-zone pixel-mappable RGB LED outer ring, all protected under a stealth filter. This unique design ensures superior color mixing, powerful output, and the ability to create captivating effects. It features a zoom range of 3.9° to 55.3°, ensuring maximum coverage with a unique lens for tight beam effects. Control and customization are seamless with prebuilt programs, multiple profiles, and advanced dimming modes, all compatible with DMX & RDM protocols. The device has an onboard USB-C port for easy software updates. With its rugged IP65 casing, this fixture is built to endure harsh conditions, making it ideal for both indoor and outdoor applications. Fast, smooth pan and tilt movements add to its performance capabilities. Despite its robust features, the unit weighs only 20lbs, allowing for easy installation and mobility.
The Rogue Outcast 1 BeamWash is a versatile, IP65 rated, lightweight LED lighting fixture. It boasts seven 45W RGBW LEDs and a 12-zone pixel-mappable RGB LED outer ring, all protected under a stealth filter. This unique design ensures superior color mixing, powerful output, and the ability to create captivating effects. It features a zoom range of 3.9° to 55.3°, ensuring maximum coverage with a unique lens for tight beam effects. Control and customization are seamless with prebuilt programs, multiple profiles, and advanced dimming modes, all compatible with DMX & RDM protocols. The device has an onboard USB-C port for easy software updates. With its rugged IP65 casing, this fixture is built to endure harsh conditions, making it ideal for both indoor and outdoor applications. Fast, smooth pan and tilt movements add to its performance capabilities. Despite its robust features, the unit weighs only 20lbs, allowing for easy installation and mobility.
Downloads
Shipping
This equipment has been inspected by a Main Light certified technician at one of our locations.
Features
- IP65 rated, suitable for indoor and outdoor applications
- Lightweight design (20lbs)
- Seven 45W RGBW LEDs for excellent color mixing and powerful output
- 12-zone pixel-mappable RGB LED outer ring for captivating visual effects
- Wide zoom range of 3.9° to 55.3° for maximum coverage
- Unique lens design for tight beam effects
- Advanced 16-bit dimming and several dimming modes
- Multiple profiles for simple and advanced control modes
- Compatibility with DMX & RDM protocols
- Onboard USB-C port for easy software updates
- Prebuilt programs for easy control and customization
- Fast, smooth pan and tilt movements
- Rugged, durable casing that can withstand harsh conditions
Specifications
- Field Angle: 5.9° to 49.8°
- Cutoff Angle: 6.7° to 55.3°
- Lumens – Source: 5,900
- Lumens – Output: 4,073
- Illuminance (3.9°): 15,308 lux @ 5 m
- Illuminance (55.3°): 473 lux @ 5 m
- Selectable PWM: 600 Hz, 1,200 Hz, 2,000 Hz, 4,000 Hz, 6,000 Hz, 15,000 Hz
- Pan and Tilt: 540°/260°
- Strobe Rate: 0 to 20 Hz
- Dimensions: 11.92 x 7.58 x 15.75 in
- Weight: 20.2 lb (9.16 kg)
- Exterior Color: Black
- Housing Material: Magnesium aluminum diecast, high impact, flame-retardant polymer
- Power Connection: Edison plug to Seetronic Powerkon IP65
- Control Protocol: DMX, RDM
- DMX Channels: 15, 24, 30, 64, 111 or 135
- Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
- Power Linking: 3 units @ 120 V; 6 units @ 208 V; 7 units @ 230 V
- IP Rating: IP65, temporary outdoor/wet use, with pressure equalizing M12 GORE valve
- Maximum Ambient Temperature (ta) 45° C / 113° F
